JQ28HB32-0674A 1.8Degree 2-phase stepper motor
Features:
1. Low Inertia, Quick Response
2. High Torque, High Efficiency
3. Low Vibration, Low Noise
4. Small Size
Quick Details:
| Model | Frame Size | Phase | Shaft Type | Body Length (mm) | Holding Torque (Nm) | Rated Current (A) |
| JQ28HB32-0674A | NEMA11(28mm) | 2 | Single Shaft | 32 | 0.06 | 0.67 |
Mechanical Size:
Wiring Diagram:
Torque Curve:
| Items | Value |
| Phase | 2 |
| Step Angle | 1.8degree |
| Radial Play | 0.02mm@450g |
| Axial Play | 0.08mm@450g |
| Max Radial force | 28N 5mm from flange |
| Max Axial Force | 7N |
| Dielectric Strength | 600VAC / 1S |
| Insulation Resistance | 100MΩ ,500VDC |
| Ambient Temperature | -20℃~ +50℃ |
| Insulation Class | Class B |
| Certification | CE |
| IP Rate | IP30 |
| Lead Wire Type | Leads |
| Shaft Type | Single shaft |
| Rotor Inertia | 9 g.cm^2 |
| Frame Size | 28 mm |
| Body Length | 32 mm |
| Holding Torque | 0.06 N.m |
| Current/Phase | 0.67 A |
| Resistance | 5.6 Ω |
| Inductance | 3.4 mH |
| Winding Type | Bipolar |
| Detent Torque | 0.005 N.m |
| Front Shaft Length | 20 mm |
| Lead Wire No. | 4 |
| Weight | 0.11 kg |
| Shaft Diameter | 5 mm |
We can supply Extra service:
If this motor do not match with your request. Please feel free to contact with us,We can make customized shaft / winding / mounting flange / cable / connector.We will works side-by-side with you and your team to design a motor that will fit the precise needs of your application. All Engineering and Support is done in-house.
Accessories service: gearbox, connector
Customized Design: Customized Winding, Customized Flange, Customized Shaft....
