| Brand Name : | Junqi |
| Model Number : | JQM-95SS3540 |
| Certification : | CE,ROHS, UL |
| Price : | USD9-usd14/pc (Negotiable) |
| Payment Terms : | L/C, T/T, Western Union,PAYPAL |
| Supply Ability : | 10000PCS/Month |
| Delivery Time : | as confirmed |
Driving Motor Data:
| Motor model | Rated Volt. | No load | Load | Stall | |||||
| Current | Speed | Current | Speed | Torque | power | Torque | Current | ||
| V | mA | rpm | mA | rpm | gf.cm | W | gf.cm | mA | |
| JQM-35400124500 | 12 | ≤50 | 4500 | ≤420 | 3600 | 96 | 3.62 | ≥430 | ≥1790 |
| JQM-35400126000 | 12 | ≤59 | 6000 | ≤513 | 5100 | 100 | 5.34 | ≥600 | ≥2180 |
| JQM-35400244500 | 24 | ≤45 | 4500 | ≤215 | 3600 | 97 | 3.66 | ≥436 | ≥910 |
| JQM-35400247000 | 24 | ≤38 | 7000 | ≤411 | 5100 | 115 | 6.14 | ≥380 | ≥1750 |
Technical Data of Gearbox:
| Reduction Stage | 3 | 4 | 5 |
| Reduction Ratio | 94K | 394K | 1166K |
| Length of Gearbox "L" mm | 16 | 16 | 16 |
| Gearbox Efficiency | 73% | 65% | 59% |
Gear Motor Mechanical Size:
Gear Motor Electric Data:
| Model Number | Rated Volt. | No Load | At Max Efficiency | Stall | |||||
| Speed | Current | Speed | Current | Torque | Power | Current | Torque | ||
| rpm | mA | rpm | mA | Kgf.cm | W | mA | Kgf.cm | ||
| JQM-95SS35400124500-94K | 12V | 48 | ≤150 | 35 | ≤800 | 9 | 3.23 | / | / |
| JQM-95SS35400128000-196K | 12V | 40 | ≤240 | 30 | ≤1400 | 16 | 4.93 | / | / |
| JQM-95SS35400247000-94K | 24V | 74 | ≤350 | 44 | ≤1000 | 10 | 4.52 | ≥1500 | ≥32 |
| JQM-95SS35400247000-394K | 24V | 17 | ≤150 | 13 | ≤550 | 30 | 4.00 | ≥2400 | ≥100 |
| JQM-95SS35400246000-1166K | 24V | 5.1 | ≤80 | 4.1 | ≤500 | 70 | 2.95 | ≥1150 | ≥300 |
| Remark: 1 Kgf.cm≈0.098 N.m≈14 oz.in 1 mm≈0.039 in | |||||||||
Remark:
Gear Motor Torque=Driving motor torque*Reduction ratio*Gearbox
efficiency;
Gear Motor Speed=Driving motor speed/Reduction ratio
Motor detailed config can be customized according to customer's
requests,
like voltage,speed,as well as shaft length and shape...
Welcome OEM or ODM projects
Notes: Above is our standard models for your reference, we can make as customer request.
Professional Factory:
Certificate Photos :
Packing:
Transportation:
Motor Application Fields:
FAQ:
Q: How long is the lead time of orders?
A:Lead time : 4 weeks after receive the deposit
Q: What is your trade Assurance?
A: 100% product quality protection.
100% product on time shipment protection.
100% payment protection for your covered amount.
Q: What’s Moq?
A: 5PCS. Small Order Welcome.
Q: Do You Make Customized Product?
A: Yes,We Accpet IT.
Q: About After Sale Serive?
A: After Sales Services 24/7.
Q: What should I do if I'm not satisfied with your product?
A: If there are defects in its quality, we can exchange a good one for you.
Generally, this problem is rare.
Q: What is the payment term?
A: T/T and Paypal is used more,please contact us for details
Q: What is the quality level of your product?
A: We produce good quality, refuse to produce low quality.
|
|
