| Brand Name : | Junqi |
| Model Number : | JQM-65SS3525 |
| Certification : | CE,ROHS, UL |
| Price : | USD5-usd8/pc (Negotiable) |
| Payment Terms : | L/C, T/T, Western Union,PAYPAL |
| Supply Ability : | 10000PCS/Month |
| Delivery Time : | as confirmed |
Driving Motor Data:
| Motor model | Rated Volt. | No load | Load | Stall | |||||
| Current | Speed | Current | Speed | Torque | power | Torque | Current | ||
| V | mA | rpm | mA | rpm | gf.cm | W | gf.cm | mA | |
| JQM-35250126000 | 12 | ≤47 | 6000 | ≤269 | 4800 | 40 | 2.0 | ≥180 | ≥1140 |
| JQM-352501211000 | 12 | ≤131 | 11000 | ≤755 | 8800 | 56 | 5.2 | ≥252 | ≥3210 |
| JQM-35250243000 | 24 | ≤12 | 3000 | ≤38 | 2400 | 26 | 0.7 | ≥117 | ≥160 |
| JQM-35250244500 | 24 | ≤15 | 4500 | ≤84 | 3600 | 38 | 1.4 | ≥171 | ≥360 |
| JQM-35250246000 | 24 | ≤30 | 6000 | ≤111 | 4800 | 40 | 2.0 | ≥180 | ≥470 |
Technical Data of Gearbox:
| Reduction Stage | 3 | 4 | 5 |
| Reduction Ratio | 40.5K, 67.5K | 135K, 225K | 450K |
| Length of Gearbox "L" mm | 12 | 12 | 12 |
| Gearbox Efficiency | 73% | 65% | 59% |
1. Main voltage: 3V, 6V, 12VDC, 24VDC
2. Typical applications: Automatic door-lock, projector,
hairdressing equipment
3. Square Gearbox size: 65*38*H12mm
4. Torque: 0.5-20kgf.cm
5. Direction: CW, CCW
6. Voltage, speed, and shaft can be customized based
7. Encoder 13PPR available
Gear Motor Mechanical Size:
Gear Motor Electric Data:
| Model Number | Rated Volt. | No Load | At Max Efficiency | Stall | |||||
| Speed | Current | Speed | Current | Torque | Power | Current | Torque | ||
| rpm | mA | rpm | mA | Kgf.cm | W | mA | Kgf.cm | ||
| JQM-65SS352501211000-225K | 12V | 50 | ≤285 | 38 | ≤1300 | 12 | 4.7 | ≥4600 | ≥50 |
| JQM-65SS35251211000-450K | 12V | 24 | ≤400 | 17 | ≤1200 | 20 | 3.5 | ≥2800 | ≥73 |
| JQM-65SS352502411000-25K | 24V | 440 | ≤150 | 220 | ≤1185 | 3 | 6.8 | ≥1800 | ≥5.3 |
| JQM-65SS352502411000-135K | 24V | 81.4 | ≤150 | 68 | ≤900 | 6.4 | 4.5 | ≥2800 | ≥30 |
| JQM-65SS35250248000-225K | 24V | 35 | ≤100 | 26 | ≤400 | 8 | 2.1 | ≥860 | ≥32 |
| Remark: 1 Kgf.cm≈0.098 N.m≈14 oz.in 1 mm≈0.039 in | |||||||||
Notes: Above is our standard models for your reference, we can make as customer request.
Professional Factory:
Certificate Photos :
Packing:
Transportation:
Motor Application Fields:
Our motor products contain range:
FAQ:
Q:How long is the lead time of orders?
A:Lead time : 4 weeks after receive the deposit
Q:What is your trade Assurance?
A:100% product quality protection.
100% product on time shipment protection.
100% payment protection for your covered amount.
Q: What’s Moq?
A: 5PCS. Small Order Welcome.
Q:Do You Make Customized Product?
A:Yes,We Accpet IT.
Q:About After Sale Serive?
A: After Sales Services 24/7.
Q: What should I do if I'm not satisfied with your product?
A: If there are defects in its quality, we can exchange a good one for you.
Generally, this problem is rare.
Q:What is the payment term?
A:T/T and Paypal is used more,please contact us for details
Q:What is the quality level of your product?
A:We produce good quality, refuse to produce low quality.
|
|
