| Brand Name : | Junqi |
| Model Number : | JQM-28PRBL2838 |
| Certification : | CE,ROHS, UL |
| Price : | USD15-usd21/pc (Negotiable) |
| Payment Terms : | L/C, T/T, Western Union,PAYPAL |
| Supply Ability : | 10000PCS/Month |
| Delivery Time : | as confirmed |
Driving Motor Data:
| Motor model | Rated Volt. | No load | Load | Stall | |||||
| Current | Speed | Current | Speed | Torque | power | Torque | Current | ||
| V | mA | r/min | mA | r/min | gf.cm | W | gf.cm | mA | |
| BL2838-012-6000 | 12 | ≤220 | 6000 | ≤360 | 4500 | 20 | 0.9 | 70 | 700 |
| BL2838-024-6000 | 24 | ≤80 | 6000 | ≤150 | 4500 | 50 | 2.3 | 160 | 230 |
Technical Data of Gearbox:
| Reduction Stage | 1 | 2 | 3 | 4 |
| Reduction Ratio | 3.7K, 5.2K | 14K, 19K, 27K | 51K, 71K, 100K, 139K | 189K, 264K, 369K, 515K, 721K |
| Gearbox Length “L” mm | 27.5 | 35.5 | 43.5 | 51.5 |
| Gearbox Efficiency | 90% | 81% | 73% | 65% |
Gear Motor Mechanical Size:
What a Model Number Tells You?
We follow some rules to create each model number. A model number would tell you a lot of useful messages. Here is a sample.
So here we can learn that it is a 37mm Round Spur gear motor, 12V driving motor #555, no load input speed 6000rpm and reduction ratio 100:1. Hey, what about output speed? You need to do a little calculation. Input speed 6000rpm ÷ reduction ratio 100 = 60rpm
Gear Motor Electric Data:
| Model Number | Rated Volt. | No Load | At Max Efficiency | Stall | |||||
| Speed | Current | Speed | Current | Torque | Power | Current | Torque | ||
| rpm | mA | rpm | mA | Kgf.cm | W | mA | Kgf.cm | ||
| JQM-28RPBL28380249000-14K | 24V | 642 | 320 | 421 | 900 | 1 | 4.32 | 1250 | 3 |
| Remark: 1 Kgf.cm≈0.098 N.m≈14 oz.in 1 mm≈0.039 in | |||||||||
1.Main voltage : 6VDC,12VDC, 24VDC
2.Typical applications: Smart Instrument, Digital product,
Automatic door-lock, Medical equipment, Security monitoring, Smart
home applicances, Robots…
3. Round Gearbox size: 28mmφ*L
4. Torque: 1kgf.cm
5. Direction: CW, CCW
6. Voltage, speed, and shaft can be customized based
